AC MainsSeriesAC mains system with multiple configuration options, safety and metering features available
- The AC Mains incoming power cabinets are integrated based on project specific requirements with switchgear, surge protection, energy meters and functionality.
- Available in various configurations and with optional features.
- Standard models in 63A, 80A, 100A
- Configuration prepared for 1-3 tenants, AC input from grid or generator, supply to site AC power distribution board.
- OPS-C single-walled Outdoor Power Cabinet, IP 65, with base material in stainless steel, powder coated in RAL 9016, and hinges and door handle in stainless steel.
- Circuit Breakers, Loads circuit breakers, manual changeover switch according to configuration
- Models with pole-mounting brackets for 75-110mm pole diameter
- Aluzinc Steel
- Powder-coated in RAL 9016
- Power Capacity: 63A, 80A, 100A
- Surge protection: class I/II
- Communication port RS 485
- IP65
- CE, UL/cUL
- RoHs/REACH/CLP
- Telcordia GR-487 capable
Request a quote
AC mains system with multiple configuration options, safety and metering features available
- The AC Mains incoming power cabinets are integrated based on project specific requirements with switchgear, surge protection, energy meters and functionality.
- Available in various configurations and with optional features.
- Standard models in 63A, 80A, 100A
- Configuration prepared for 1-3 tenants, AC input from grid or generator, supply to site AC power distribution board.
- OPS-C single-walled Outdoor Power Cabinet, IP 65, with base material in stainless steel, powder coated in RAL 9016, and hinges and door handle in stainless steel.
- Circuit Breakers, Loads circuit breakers, manual changeover switch according to configuration
- Models with pole-mounting brackets for 75-110mm pole diameter
- Aluzinc Steel
- Powder-coated in RAL 9016
- Power Capacity: 63A, 80A, 100A
- Surge protection: class I/II
- Communication port RS 485
- IP65
- CE, UL/cUL
- RoHs/REACH/CLP
- Telcordia GR-487 capable
Products within the series
Product filters
Product filters
| Product | Rated power | Mounting | Width | Height | Depth | Material | Std. color |
|---|---|---|---|---|---|---|---|
| AC Mains Board 63A | 63A, 3 x 380VAC | Free-Standing | 500 mm19.7 in | 900 mm35.4 in | 350 mm13.8 in | Aluzinc Steel | RAL 9016 |
| AC Mains Board 100A | 100A, 3 x 380VAC | Free-Standing | 500 mm19.7 in | 900 mm35.4 in | 350 mm13.8 in | Aluzinc Steel | RAL 9016 |
Request a quote or technical guidance
Provide your technical requirements and our team will prepare a tailored recommendation and quotation.
