VKC Liquid CoolingSeries
The VKC Liquid Cooling series is a compact panel-mounted precision cooling system for BESS, EDGE, telecom, and industrial applications requiring strict thermal control. With variable cooling capacity, glycol-based fluid flow, and advanced monitoring capabilities, VKC supports reliable temperature management for sensitive electronics and energy storage systems.
- Panel-mounted precision liquid cooling system
- 5,000–15,000 W | 17,000–51,000 BTU/h cooling capacity
- Designed for BESS, EDGE, telecom, and industrial applications
- Advanced controller platform with monitoring capabilities
- Glycol cooling solution
- Optional emergency exhaust system
Designed for BESS and EDGE applications with sensitive electronics and energy storage systems that require strict thermal control.
- Battery energy storage systems
- EDGE data center solutions
- Telecommunications equipment
- Industrial automation
- Security and defense systems
- Precision temperature control with variable cooling capacity
- Variable fluid flow for stable thermal regulation
- User-friendly display interface
- Alarm output and password-protected set point adjustment
- N+1 redundancy functionality
- Day and night mode operation
- Soft-starting functionality
- Easy maintenance with low point drains and accessible service design
- Cooling capacity: 5,000–15,000 W | 17,000–51,000 BTU/h
- Voltage options: 460V 3-phase AC / 380V 3-phase AC / 230V AC
- Operating temperature: -26°C to +50°C | -15°F to +122°F
- Cooling solution: Glycol mix, 0°F
- Refrigerant: CFC-free R454B
- Compressor: variable capacity compressor with EXV
- Pump: variable flow fluid pump
- Communication interface: Modbus RTU standard, optional SNMP card
- CE / UL / cUL
- IP65
- NEMA 3R / 4 / 4X options
- Telcordia GR-487 capable
- RoHS / REACH / CLP compliant
Products within the series
Product filters
Product filters
| Product | Cooling capacity | Voltage | Width | Height | Depth | Refrigerant | Material |
|---|---|---|---|---|---|---|---|
| VKC 5000 Slim A2 | 5000W17100 BTU/H | 1 x 230V AC | 375 mm14.8 in | 901 mm35.5 in | 208 mm8.2 in | R1234yf | AluZinc Steel |
| VKC 5000 Slim A3 | 5000W17100 BTU/H | 3 x 380V AC | 375 mm14.8 in | 901 mm35.5 in | 208 mm8.2 in | R1234yf | AluZinc Steel |
| VKC 5000 Slim A5 | 5000W17100 BTU/H | 3 x 460V AC | 375 mm14.8 in | 901 mm35.5 in | 208 mm8.2 in | R1234yf | AluZinc Steel |
| VKC 10000 Slim A2 | 10000W34100 BTU/H | 1 x 230V AC | 562 mm22.1 in | 1352 mm53.2 in | 312 mm12.3 in | R1234yf | AluZinc Steel |
| VKC 10000 Slim A3 | 10000W34100 BTU/H | 3 x 380V AC | 562 mm22.1 in | 1352 mm53.2 in | 312 mm12.3 in | R1234yf | AluZinc Steel |
| VKC 10000 Slim A5 | 10000W34100 BTU/H | 3 x 460V AC | 562 mm22.1 in | 1352 mm53.2 in | 312 mm12.3 in | R1234yf | AluZinc Steel |
| VKC 15000 Slim A2 | 15000W51200 BTU/H | 1 x 230V AC | 750 mm29.5 in | 1803 mm71 in | 417 mm16.4 in | R454b | AluZinc Steel |
| VKC 15000 Slim A3 | 15000W51200 BTU/H | 3 x 380V AC | 750 mm29.5 in | 1803 mm71 in | 417 mm16.4 in | R454b | AluZinc Steel |
| VKC 15000 Slim A5 | 15000W51200 BTU/H | 3 x 460V AC | 750 mm29.5 in | 1803 mm71 in | 417 mm16.4 in | R454b | AluZinc Steel |
Request a quote or technical guidance
Provide your technical requirements and our team will prepare a tailored recommendation and quotation.
