VTE Thermoelectric enclosure coolersSeries
The VTE series consists of panel-mounted thermoelectric enclosure coolers designed for installations where compressor-based air conditioners are not suitable. With cooling capacities from 300-1400 BTU | 100-400 W and both DC and AC power options, VTE coolers provide reliable cabinet cooling for sensitive electronics in telecom and industrial enclosures.
- 300-1400 BTU | 100-400 W thermoelectric cooling capacity
- 24–48V DC and 115–230V AC power options
- Panel-mounted thermoelectric cooling system
- Integrated cooling and heating functionality
- Modbus RTU communication interface
- IP68 protection with UL 50 Type 4 rating
- CE, UL / cUL certified
Designed for enclosures with sensitive electronics that require stable temperature control.
- Communications equipment
- Industrial equipment
- Factory automation
- Smart control system
- Cooling capacity regulation
- Integrated heating function
- Standard Modbus RTU communication interface
- Alarm output
- Password protected set point adjustment
- Automatic self-test functionality
- Cooling capacity: 300-1400 BTU | 100-400 W
- Power supply: 24–48V DC or 115–230V AC
- Panel-mounted installation
- Aluzinc housing as standard (other materials optional)
- CE
- UL / cUL
- IP68
- UL 50 Type 4
- Telcordia GR-487 capable (outdoor)
- RoHS / REACH / CLP compliant
Products within the series
Product filters
Product filters
| Product | Cooling capacity | Voltage | Width | Height | Depth | Material |
|---|---|---|---|---|---|---|
| VTE 100 AC TE A1 | 100W300 BTU/H | 115V AC | 250 mm9.8 in | 185 mm7.3 in | 170 mm6.7 in | Aluzinc Steel |
| VTE 100 AC TE A2 | 100W300 BTU/H | 230V AC | 250 mm9.8 in | 185 mm7.3 in | 170 mm6.7 in | Aluzinc Steel |
| VTE 100 DC TE D2 | 100W300 BTU/H | 24V DC | 250 mm9.8 in | 185 mm7.3 in | 170 mm6.7 in | Aluzinc Steel |
| VTE 100 DC TE D3 | 100W300 BTU/H | 48V DC | 250 mm9.8 in | 185 mm7.3 in | 170 mm6.7 in | Aluzinc Steel |
| VTE 200 AC TE A1 | 200W700 BTU/H | 115V AC | 400 mm15.7 in | 185 mm7.3 in | 170 mm6.7 in | Aluzinc Steel |
| VTE 200 AC TE A2 | 200W700 BTU/H | 230V AC | 400 mm15.7 in | 185 mm7.3 in | 170 mm6.7 in | Aluzinc Steel |
| VTE 200 DC TE D2 | 200W700 BTU/H | 24V DC | 400 mm15.7 in | 185 mm7.3 in | 170 mm6.7 in | Aluzinc Steel |
| VTE 200 DC TE D3 | 200W700 BTU/H | 48V DC | 400 mm15.7 in | 185 mm7.3 in | 170 mm6.7 in | Aluzinc Steel |
| VTE 400 AC TE A2 | 400W1400 BTU/H | 230V AC | 450 mm17.7 in | 185 mm7.3 in | 170 mm6.7 in | Aluzinc Steel |
| VTE 400 DC TE D3 | 400W1400 BTU/H | 48V DC | 450 mm17.7 in | 185 mm7.3 in | 170 mm6.7 in | Aluzinc Steel |
Request a quote or technical guidance
Provide your technical requirements and our team will prepare a tailored recommendation and quotation.
